[Supplementary Figure 8] show that PSC fabricated on NiO + MeO-2PACz using PC 25 performed better
x
than those made using other PC conditions. The results for TA devices fabricated on NiO HTL + MeO-
x
2PACz are also included.

CONCLUSIONS
In this work, we demonstrate that UV-vis absorbance can function as an effective metric for training a
BO-GP model to predict optimal PC conditions for making high-quality MAPbI films. We identified an
3
optimal MAPbI PC condition (PC 25), which produces a UV-vis spectrum closely matching that of the TA
3
MAPbI , achieving similarity metric values significantly better than other PC conditions. Material
3
characterization shows that PC 25 produces smooth MAPbI films with large grains and high crystallinity.
3
Additionally, we used an AI-based segmentation model to determine grain size from SEM images, offering a
quick and more effective analysis alternative to the standard ASTM E112-13 line intercept method. As a
final test, we present p-i-n PSC results using NiO as the HTL. Despite the high quality of MAPbI films
x
3
made using PC 25, the PSC performance is degraded due to MAPbI /NiO interfacial reaction from PC
x
3
processing. Inserting a buffer layer of MeO-2PACz brings average PCEs comparable to that of PSCs made
with TA MAPbI . These results indicate the importance of a high-quality perovskite active layer and
3
possible interactions between the active layer and charge transport layers that cannot be predicted by the
quality of perovskite films alone. When developing a ML framework for process optimization, careful
consideration of device architecture and adjacent materials is needed to define the objective for the BO-GP
models.
