Shi et al. Energy Mater 2023;3:300036 Energy Materials
DOI: 10.20517/energymater.2023.27

Article Open Access

Nanostructured block copolymer single-ion

conductors for low-temperature, high-voltage and
fast charging lithium-metal batteries

7
1
5
2
8
3,4
3,6
Junli Shi , Huu-Dat Nguyen , Zhen Chen , Rui Wang , Dominik Steinle , Lester Barnsley , Jie Li , Henrich
3,6
5
Frielinghaus , Dominic Bresser , Cristina Iojoiu 2,9,* , Elie Paillard 8,*
1
Helmholtz-Institute Muenster (IEK 12), Forschungszentrum Juelich GmbH, Münster 48149, Germany.
2
Univ. Grenoble Alpes, Univ. Savoie Mont Blanc, CNRS, Grenoble INP (Institute of Engineering Univ. Grenoble Alpes), LEPMI,
UMR5279, Grenoble 38000, France.
3
Helmholtz Institute Ulm (HIU), Ulm 89081, Germany.
4
Key Laboratory of Engineering Dielectric and Applications (Ministry of Education), School of Electrical and Electronic
Engineering, Harbin University of Science and Technology, Harbin 150080, Heilongjiang, China.
5
Juelich Centre for Neutron Science at MLZ, Forschungszentrum Juelich GmbH, Garching 85747, Germany.
6
Karlsruhe Institute of Technology (KIT), Karlsruhe 76021, Germany.
7
Australian Synchrotron, The Australian Nuclear Science and Technology Organisation (ANSTO), Clayton 3168, Australia.
8
Politecnico di Milano, Dept. of Energy, Milan 20156, Italy.
9
Réseau sur le Stockage Electrochimique de l’Energie (RS2E), CNRS FR3459, Amiens Cedex 80039, France.
* Correspondence to: Prof. Cristina Iojoiu, Université Grenoble Alpes, LEPMI, Grenoble 38000, France; CNRS, LEPMI, Grenoble
38000, France. E-mail: cristina.iojoiu@lepmi.grenoble-inp.fr; Prof. Elie Paillard, Department of Energy, Politecnico di Milano,
Milan 20156, Italy. E-mail: elieelisee.paillard@polimi.it
How to cite this article: Shi J, Nguyen HD, Chen Z, Wang R, Steinle D, Barnsley L, Li J, Frielinghaus H, Bresser D, Iojoiu C, Paillard
E. Nanostructured block copolymer single-ion conductors for low-temperature, high-voltage and fast charging lithium-metal
batteries. Energy Mater 2023;3:300036. https://dx.doi.org/10.20517/energymater.2023.27
Received: 17 Apr 2023 First Decision: 8 May 2023 Revised: 29 May 2023 Accepted: 20 Jun 2023 Published: 21 Jul 2023
Academic Editor: Wei Tang Copy Editor: Fangyuan Liu Production Editor: Fangyuan Liu
Abstract
Herein, a single-ion polymer electrolyte is reported for high-voltage and low-temperature lithium-metal batteries
-2
that enables suppressing the growth of dendrites, even at high current densities of 2 mA cm . The nanostructured
electrolyte was introduced into the cell by mechanically processing the polymer powder via an easily scalable
process. Important for the potential application in commercial battery cells is the finding that it does not induce
aluminum corrosion at high voltages and leads to low interfacial resistance with lithium metal. These beneficial
characteristics, in combination with its high single-ion conductivity and its high anodic stability, allow for the stable
cycling of state-of-the-art lithium-ion cathodes, such as NMC and NMC , in combination with a lithium metal
111 622
anode at 20 °C and even 0 °C for several hundred cycles.
Keywords: Polymer electrolyte, single-ion conductor, lithium metal, NMC, battery
